The Eoslift CPD30 4-Wheel Electric Forklift is a high-capacity, reliable solution designed for heavy-duty material handling. With a lifting capacity of up to 6,600 lbs, this forklift combines robust construction, advanced electric power, and ergonomic design to optimize performance in warehouses, distribution centers, and industrial environments.

Key Features

\n
• Electric Counterbalance Forklift – Efficient, emission-free operation.
\n
• AC Driving Motor with CURTIS Controller – Smooth and precise control for better maneuverability.
\n
• High-Capacity Battery – 80V 400Ah lead-acid battery for extended work hours.
\n
• Hydraulic Steering & Pneumatic Tires – Stable, comfortable, and safe handling.
\n
• Ergonomic Luxury Seat – Adjustable anti-fatigue seat with curved mirror.
\n
• Intelligent LED Display – Large, clear screen for easy monitoring and intuitive interface.
\n
• Safety Features – AC drive system, hand brake, foot hydraulic pedal brake, quick cut-off valve, and lowering speed limit valve.
\n

Performance Highlights

\n
• Compact Front Overhang Design – Improves stability and reduces energy consumption.
\n
• Horizontal Motor & Low-Battery Placement – Enhances driving stability.
\n
• High-Efficiency Drive Axle Box – Better climbing ability, reduced noise, and lower energy use.
\n
• Optimized Lifting & Driving Speeds – 11.81 / 18.89 in/s lifting speed, 6.21 m/h driving speed (load/unload).
\n
• Multi-Angle Adjustable Seat – Ensures operator comfort during long shifts.
\n

Specifications

\n
• Model: CPD30
\n
• Mast Type: Duplex
\n
• Power Type: Battery
\n
• Operation Type: Seated
\n
• Rated Capacity: 6,613.87 lbs
\n
• Load Center: 19 in.
\n
• Wheelbase: 54 in.
\n
• Service Weight (inc. battery): 6,393 lbs
\n
• Tires: Pneumatic (Load: 5.11~8.07 in, Drive: 6.29 x 9.05 in)
\n
• Number of Wheels: 2x/2
\n
• Wheel Tread, Load Side: 36.6 in
\n
• Mast Closed Height: 78.54 in
\n
• Free Lift Height: 5.31 in
\n
• Lift Height: 118.11 in
\n
• Extended Mast Height w/ Load-Backrest: 158.66 in
\n
• Overall Dimensions (L x W): 126.18 in x 43.7 in
\n
• Fork Size (L x W x H): 42.12 in x 3.93 in x 1.37 in
\n
• Fork Outside Width: 8.74–39.37 in
\n
• Mast Ground Clearance: 3.34 in
\n
• Turning Radius: 78.74 in
\n

Performance & Power

\n
• Driving Speed (load/unload): 6.21 m/h
\n
• Lifting Speed (load/unload): 11.81 / 18.89 in/s
\n
• Lowering Speed (load/unload): 14.96 / 14.17 in/s
\n
• Max Gradeability (load/unload, S2-5min): 14/15%
\n
• Drive Motor: AC 6.8 kW
\n
• Lifting Motor: DC 8.2 kW
\n
• Battery Voltage/Capacity: 48 V / 400 Ah
\n
• Battery Weight: 1,421.98 lbs
\n
• Steering System: Hydraulic
\n

Why Choose the Eoslift CPD30?

With 4-wheel stability, precise controls, and ergonomic design, the Eoslift CPD30 ensures safe and efficient handling of heavy loads in tight spaces. Its durable construction and energy-efficient electric powertrain make it ideal for high-demand industrial applications, increasing productivity while reducing operational costs.

Available at stoolby.com

Upgrade your material handling capabilities with the Eoslift CPD30 4-Wheel Electric Forklift—powerful, reliable, and designed for peak performance. Explore more at stoolby.com and bring efficiency and safety to your warehouse or industrial operations.
